Especificações

120mm Fan Options: 5

140mm Fan Options: 2

Application: Desktop

Brand Name: Jonsbo

Case Tamanho: 370mm x 186mm x 295mm

Case Peso: 6.5

Chassis Tipo: Desktops

Choice: yes

Dust Filters: TOP

Form Factor: MicroATX

Front Ports: USB 3.2 Gen 1 Tipo-AX1,USB 3.2 Gen 2 Tipo-CX1,

High-concerned chemical: None

Internal 2.5" Drive Bays: 3

Internal 3.5" Drive Bays: 1

material: Aluminum alloy

Max CPU Cooler Altura: 160

Max GPU Comprimento: 363

Max PSU Comprimento: 140

Modelo Number: Z20

Origin: Mainland China

Potência Modelo: ATX

Potência Supply Mounted: TOP

RGB Support: NO RGB

Radiator Tamanho: 240 MM

Series: Z20

Tipo: Horizontal

com Fan: no

com Potência Supply: no

com Side Panel Window: Yes

semi_Choice: yes

Z20 tempered glass plate

Building a compact desktop console, although full of fun, also faces many trade-offs. As the Tamanho of the chassis shrinks, the conflicts between compatibility, heat dissipation, e installation experience gradually increase. Therefore, only a few experienced users have a clear construction concept e assembly ability. In this regard, we constantly consider how to optimize the design, maintain a compact hardware layout, e improve internal hardware compatibility, ultimately allowing more users to experience the practicality e fun of miniaturized models:●The main body Tamanho is 370mm * 186mm * 295mm (Comprimento * Largura * Altura, excluding protrusions such as handles/foot pads), com a volume of only about 20L ●Integrated bending of outer frame, sheet thickness up to 2mm/equipped com detachable e portátil handle ●Compatível com 60mm thickness (30mm cold exhaust+fan) performance level 240 water-cooled or 160mm Altura double tower air-cooled radiator ● Supports high-performance graphics cards com a Comprimento limit of 363mm e full-Tamanho Micro-ATX motherboards ●At least 15cm ATX Potência supply is supported in air-cooled mode, e at least 14cm ATX Potência supply is supported in water-cooled mode ● Optimized installation experience design: achieving flexible e versatile hardware combinations in a small space

Product parameters

Product Modelo: Z20 white/black Case Tamanho (excluding protrusions such as handles/feet): 370mm x 186mm x 295mm (depth/Largura/Altura) Case Tamanho (including protrusions such as handles/feet): 382mm x 198mm x 335mm (depth/Largura/Altura) Motherboard support: Mini ITX/Micro ATX Expansion slot: 4 Case material: SPCC steel plate, tempered glass Peso: net Peso 5kg/gross Peso 6.5kg CPU air-cooled heat sink: Altura limit 160mm CPU water-cooled heat sink: top, 240mm GPU Compatível Tamanho: limited to 363mm in Comprimento, depending on other hardware configurations ATX PS2 Potência supply compatibility: limited to 180mm in Comprimento, recommended Comprimento ≤ 140mm, depending on other hardware configurations SFX Potência compatibility: SFX/SFX-L Front I/O interface: USB 3.2 Gen 1 Tipo-Ax1, USB 3.2 Gen 2 Tipo-Cx1, headphoneµphone composite audio port x1 Drive bits: 2.5 inches: up to 3, the specific number of assemblies depends on other hardware configurations 3.5 inches: up to 1, the specific number of assemblies depends on other hardware configurations Fan support: top 2 x 120mm/2 x 140mm, rear 1 x 120mm/1 x 92mm, bottom 2 x 120mm/2 x 140mm, specific assembly Quantidade depends on other hardware configurations
